Iron Removal — AIRP
Advanced Iron Removal Plant
The AIRP uses KATALOX LIGHT — German-made, NSF/ANSI-61 & 372 certified media — to remove iron up to 29 ppm. Fully automated with Multiport Valve (A-MPV). 5-year media warranty.
Technical Process (3 Stages)
1
NaOCl Dosing
Chemical dosing (0.8–2.0 L/hr @ 10%) for oxidation, disinfection and media fouling prevention. Automatic dosing pump.
2
Iron Filtration
KATALOX LIGHT media in 36"×72" FRP vessel. Auto backwash based on pre-set time. Min 1,540L media capacity.
3
Carbon Polishing
Activated carbon filter removes taste, odour, residual chlorine. FRP 36"×72" or 48"×72". 450–1,000L media.
A-MPV Advantages
Hassle-free automated rinsing, filtration & backwashing
Reduces excess power consumption and prevents water wastage
Extends AIRP life and maintains efficiency
Protects from dry running and overloading
Remote monitoring capability — view plant status anywhere
Auto pump on/off — prevents tank overflow
Error message display for instant fault detection
NSF-61 Certified FRP Pressure Vessels
Tata-make FRP Pressure Vessel — NSF/ANSI-61 Certified — 36"×72" & 48"×72" models
Available Capacities
| System | Range |
|---|---|
| Iron Removal (AIRP) | 1,000–40,000 LPH |
| Iron & Arsenic | 1,000–40,000 LPH |
| Fluoride Removal | 1,000–40,000 LPH |
| Project-based | Higher capacity available |
Warranty Terms
| Iron Media (KATALOX) | 5 Years |
| Arsenic Media (TITANSORB) | 5 Years |
| Fluoride Media (SAFEDEF) | 5 Years |
| FRP Pressure Vessel | 12 Years |
| UPVC Items | 7 Years |
| Multiport Valve (MPV) | 18 Months |
| Carbon Media | 12–18 Months |
| Dosing Pump | 18 Months |
